Introduction of 72V 3KW Hairpin 140 PMSM Auto Rickshaw Motor and Controller
”
Introduction of 72V 3KW Hairpin 140 PMSM Auto Rickshaw Motor and Controller
PMSM
Sensor Hairpin Stator
Controller
Parameters | ||
1 | Motor Type | PMSM |
2 | Rated Power | 3KW |
3 | Rated Voltage | 60-72V |
4 | Rated Speed | 3000RPM |
5 | Peak Speed | 7000RPM |
6 | Max Efficiency | ≥94% |
7 | Sensor Type | Rotating Transformer |
8 | Stator Structure | 60 Groove |
9 | Rotor Structure | V type |
10 | Polars | 5 Polars |
11 | Magnetic Steel Type | Straight |
12 | IP level | IP65 |
14 | Peak Torque | 75NM |
15 | Motor size | Φ164*250 |
Road Test Report | |
GVW | 950kg |
Passengers | 7+1 |
Max speed @Driver only | 51-56KM/H |
Speed @ Driver+7 | 46-51KM/H |
Full-load Battery Current | 45-60A |
Gradeability | 8-20° |
Full-load Climbing Speed | 20-28KM/H |
